Swimming Pool Refurbishment Complete

Swimming pool refurbishmentA swimming pool refurbishment has successfully completed just in time for the sun coming out this weekend. The existing outdoor pool overlooks a cotswold valley and required a complete refurbishment. The pool had fallen into a sorry state after nearly 40 years of use so needed stripping out for a complete refurbishment and bringing up to date with the latest plant room equipment.

The pool had previously been covered with a bubble solar cover but as part of the refurbishment they required a new automated hidden slatted cover system.

The structure of the existing pool shell had stood up to ther test of time but new structural calcs were required to add on a new ‘letterbox style’ cover pit; which was constucted behind the existing shallow end wall.

Read More…

New build basement swimming pool

Digging a basement pool hallSite excavation work has started on a new build basement swimming pool in London. The pool will be 20 meters in length and will have 2 depths with sloped riser between them. The shallow water depth is 1.3m going down to a deep end water depth of 2m.

The pool will be a skimmer pool with a 150mm freeboard to the surround floor tiles, it will also benefit from a remotely controlled hidden thermal slatted cover.

The pool hall will be built from scratch and will be located below an existing garden.

Working closely with the architects and mira construction, Brookforge will be designing, building, tanking, tiling and piping up everything pool related.

The plant room and all the associated equipment will be installed and tested by Brookforge as well as the pool hall air handling, dehumidification and ducting systems. Read More…

Slatted thermal pool cover installed and tested in Pershore

Slatted thermal pool cover closing Slatted thermal pool cover Slatted thermal pool cover on overflow pool ICF Swimming Pool Slotted Overflow Pool Pershore new build swimming pool

A recently completed project in Worcestershire was a new build fully insulated deck level pool. It benefited from the latest energy saving technology in the automated plantroom and a remote controlled slatted thermal pool cover which is hidden away in the floor of the pool.

Working directly with the Architect from first conception meant that everything pool related could be taken into account during the pool hall design.

The final result is a contemporary and stylish pool that blend modernity with functionality.

Slatted thermal pool cover benefits

The benefits of a slatted thermal pool cover should not be underestimated; not only will it keep your pool water warm whilst you are not using it thus saving on the running costs. They also prevent water evaporation, meaning your dehumidification system will have less work to do keeping the pool hall humidity stable and thus protecting the fabric of your pool hall.

REF: [12-408]

Concrete Poured, Pershore

Insulated ICF overflow pool shell during construction

Concrete Pour Successful

The pool shell is cast in a single pour, a homogeneous structure is far stronger than a traditional concrete block construction.

The difference in level is to accommodate a cover which is hidden in a ‘pit’. The cover is an insulated slatted design, and features an automatic system which can be controlled wirelessly.

Quad-Lock ICF System

As the Quad-Lock panels act as shuttering for the pour, the result is clean without the wastage of ply shuttering. Quad-Lock is a modular system, which enables quick construction of insulated structures. Brookforge have adapted this system for use with swimming pool construction.

[12-408]

New Basement Pool Project, London: Slab Installation

Reinforced concrete slab designed to withstand the force of a large volume of water. The following day, construction of the pool shell can begin. It doesn’t take long before the shape of the final product emerges.

[12-1129]
